RM-2U2029 - RM-2U2029
RM-2U2029 has a unique space-saving design. Two 5.25" open bays support innovation combination. It can support different version of Micro ATX and ATX M/B (up to 12" x 13 "). 2U size case is with 3U capacity plus your creative ideas. This Rack Mount IPC case comes with PS2 high efficiency True Green Power Supply (750W, 850W, 950W) and gives many options to support your custom. Four 80mm ball bearing intake fans create excellent airflow for system temperature control.
RM-2U2029 - RM-2U2029
| Model | RM-2U2029 |
|---|---|
| Product Category | Discontinued Rackmount |
| Form Factor | 2U |
| Cage Color | Black |
| Specifications | 19" Rackmount standard |
| MotherBoard Size |
MicroATX (9.6 in. x 9.6 in.) ATX (12 in. x 9.6 in.) E-ATX (12 in. x 13 in.) |
| Air Filter | Removable & Washable |
| Drive Bay |
5.25" x 2 (Open) 3.5" x 9 (Hidden) |
| External Bay | 5.25" x2 (External) |
| Internal Bay | 3.5" x8 (Internal) |
| Switch |
Power On/Off Reset Fan Alarm |
| Power Supply | Standard PS2 Size Power Supply |
| Cooling Fan | 4 x 80mm Intake Fans (Front Panel with Airfilter) |
| Indicators | LED's for Power, HDD LAN |
| Dimension | 19" x 3.5" x 25.98" ( W x H x D ) |
| Weight | 32.00lb |
| Warranty | 1 Year Manufacture Limited Warranty |
RM-2U2029 - RM-2U2029
RM-2U2029 - RM-2U2029
| Components |
|---|
| AP-P4ATX65FE (Power Supply | PS2) |
| Components |
|---|
| AP-P4ATX75FEP (Power Supply | PS2) |
| Components |
|---|
| AP-P4ATX85FEP (Power Supply | PS2) |
| Components |
|---|
| AP-P4ATX95FEPC (Power Supply | PS2) |
RM-2U2029 - RM-2U2029
| RM-SLIDER20 | 2U-4U 20" length Slider Rail. This is a full-travel 3-sections Solid-Bearing Slider Rail. Lock open and quick release latch for easy chassis removal. |
| RM-SLIDER24 | 2U-4U 24" length Slider Rail. This is a full-travel 3-sections Solid-Bearing Slider Rail. Lock open and quick release latch for easy chassis removal. |
| RM-SLIDER26 | 2U-4U 26" length Slider Rail. This is a full-travel 3-sections Solid-Bearing Slider Rail. Lock open and quick release latch for easy chassis removal. |
RM-2U2029 - RM-2U2029
