The Athena Power AP-PS2MK12P868 is a 1200W industrial-grade power supply built for high-performance systems. Fully compliant with ATX 3.1 and PCIe 5.0 standards, it’s ideal for workstations, servers, and GPU-heavy applications. Featuring the next-gen 12V-2x6 (H++) connector, dual smart fans, and 80 PLUS Platinum efficiency, this PSU delivers stable, quiet, and energy-efficient power.
Key Features:
-
1200W Output: Reliable continuous power for demanding builds
-
80 PLUS Platinum Certified: Up to 92% energy efficiency
-
ATX 3.1 & PCIe 5.0 Ready: Future-proof for next-gen systems
-
12V-2x6 (H++) Connector: Safe, high-current delivery for powerful GPUs
-
Dual Smart Cooling Fans: Quiet, thermal-controlled airflow
-
Universal AC Input (100–240V): Global deployment-ready
-
Low Ripple Output: Ideal for audio/video and mission-critical systems
-
Certified to IEC/UL 62368-1: International safety compliance
-
Full Connector Support: Includes ATX, EPS-12V, PCIe, SATA, Molex, 12V-2x6
AP-PS2MK12P868 - AP-PS2MK12P868
| Model | AP-PS2MK12P868 | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Product Category | PS2 | ||||||||||||
| Product Sub Category | PS2 Power Supplies | ||||||||||||
| Output Power | 1200 Watts | ||||||||||||
| Input Votage | 88 ~ 264 Volts AC | ||||||||||||
| Frequency | 47/63 Hz | ||||||||||||
| Temperature Range | Operating: 0°C ~ +50°C on Full Load; Storage & Shipping: -20°C ~ +80°C | ||||||||||||
| MTBF | 100,000 Hours on Maximum Load at +25°C | ||||||||||||
| Rise time | Less than 20 ms | ||||||||||||
| Hold-up Time | 17 ms Minimum at Nominal Input Voltage | ||||||||||||
| Output |
|
||||||||||||
| Connectors |
ATX Connector 24 (20+4) Pin x 1 12V-2x6(H++) 600W Connector x 1 EPS-12V 8 Pin x 1 + 8 Pin (4+4) x 1 PCIE 6+2 Pin x 2 SATA 15 Pin x 8 PCIE 6 6 Pin x 2 SATA 15 Pin x 8 Molex 4 Pin x 2 |
||||||||||||
| Dimension | (D x W x H) 158 x 150 x 86 mm / 6.22 x 5.9 x 3.4 in | ||||||||||||
| Weight | 6.00lb | ||||||||||||
| Warranty | 3 Year Manufacture Limited Warranty |
