Output Wattage

• 860W

Dimension (L x W x H)

• 160x150x86(mm)
• 6.3x5.91x3.39(inch)

Input Specs

• VOLTAGE: 90 ~ 264 VAC FULL RANGE
• FREQUENCY : 47 ~ 63 HZ
• INPUT CURRENT: 12 A ( RMS ) FOR 115VAC / 6A ( RMS ) FOR 230VAC
• INRUSH CURRENT: 20A MAX. FOR 115 VAC / 40A MAX. FOR 230 VAC
• PFC CAN REACH THE TARGET OF 95% @230V, FULL LOAD

Key Features

• TEMPERATURE RANGE: OPERATING 0℃ ~ 50℃
• HOLD UP TIME: WHEN POWER SHUTDOWN DC OUTPUT 5V MUST BE MAINTAIN 16MSEC IN REGULATION LIMIT AT NORMAL INPUT VOLTAGE
• HUMIDITY: OPERATING:20%-80%, NON-OPERATING:10%-90%
• EFFICIENCY: TYPICAL 80-85% AT 25℃ 115V FULL LOAD
• OVER POWER PROTECTOIN: 110%~150%
• OVER VOLTAGE PROTECTION: +3.3V→3.6~4.3V, +5V→5.8~6.7V, +12V→13.2~15V
• OVER CURRENT PROTECTION: +3.3V→29.7~40.2A, +5V→29.7~40.2A, +12V→63.7~86.2A
• SHORT CIRCUIT PROTECTION: +5V, +3.3V, +12V, -12V
• RESTART AFTER PROTECTION: IF THE PSU IS USING AC POWER SWITCH TO CONTROL ON/OFF, IT HAS TO BE SWITCHED OFF AT LEAST FOR 5 SECONDS TO RESTART THE UNIT
• SAFETY: TO MEET UL, CUL, TUV, CCC
• COOLING: ONE 60 mm DC FAN

**THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
