OUTPUT WATTAGE

• 600W
• REMARKS: +5V AND +3.3V TOTAL OUTPUT MAX: 170W

BEST SOLUTION FOR

• Server ,Workstation ,Storage System

DIMENSION

• 276x101x82(mm)
• 10.87x3.98x3.23(inch)

INPUT SPEC

• VOLTAGE: FULL RANGE 100~240 VAC
• FREQUENCY: 50Hz/60Hz (+/-3Hz)
• STEADY-STATE CURRENT: 9.0~4.0 AMPS MAXIMUM AT ANY LOW/HIGH RANGE INPUT VOLTAGE
• INRUSH CURRENT: 35A/70A @ 115/230 VAC
• POWER FACTOR CORRECTION: PHC CAN REACH THE TARGET OF 95% @ 230V, FULL LOAD

FEATURES

• TEMPERATURE RANGE: OPERATING: 0 ℃ ~ 40 ℃, STORAGE: -20 ℃ ~ 80 ℃
• HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & NORMAL INPUT VOLTAGE
• EFFICIENCY: >80% TYPICAL AT 115V, 20~100% MAX LOAD
• POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms
• OVER POWER PROTECTION: 110~180%
• OVER VOLTAGE PROTECTION: +5V: 5.9~6.7V, +3.3V: 3.9~4.3V, +12V: 13~15V
• OVER CURRENT PROTECTION: +3.3V: 27.5~37.5A, +5V: 27.5~37.5A, +12V: 52.8~76.8A
• SHORT CIRCUIT PROTECTION: +5V, +3.3V, +12V
• SAFETY: TO MEET UL, CUL, TUV, CCC
• REMOTE ON/OFF CONTROL
• WARNING METHOD: AUDIO ALARM, FAULT LED, TTL

*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
