OUTPUT WATTAGE

750W

* POWER MODULE TOTAL OUTPUT POWER OF +5V AMD +3.3V NOT EXCEED 210W



BEST SOLUTION FOR

Server ,Workstation ,Storage System



DIMENSION

355x106x41.8(mm)

13.98x4.17x1.65(inch)



INPUT SPEC

VOLTAGE： 90～264VAC FULL RANGE

FREQUENCY： 47～63HZ

INPUT CURRENT：6A（RMS）FOR 230VAC; 12A（RMS）FOR 115VAC

INRUSH CURRENT：15A MAX. FOR 115 VAC PER MODULE; 30A MAX. FOR 230 VAC PER MODULE



FEATURES

* TEMPERATURE RANGE：OPERATING 0℃～50℃，STORAGE -20℃～80℃

* HOLD UP TIME：11mS MIN. AT FULL LOAD & 115 VAC INPUT VOLTAGE

* DIELECTRIC WITHSTAND：INPUT/OUTPUT 1500 VAC FOR 1 MINUTE

* INPUT TO FRAME GROUND 1500 VAC FOR 1 minute

* EFFICIENCY：TYPICAL 85% AT 115V, 12V/54A 5VSB/0.4A; TYPICAL 88% AT 230V, 12V/54A 5VSB/0.4A

* POWER GOOD SIGNAL：ON DELAY 100mS TO 500mS，OFF DELAY 1mS

* OVER POWER PROTECTION：110～150% MAX

* OVER VOLTAGE PROTECTION：+3.3V→3.7~4.1V, +5V→5.7~6.5V, +12V→12.8~13.9V

* SHORT CIRCUIT PROTECTION: +5V, +3.3V, +12V, -12V

* SAFETY：TO MEET UL, CUL, TUV

* FAULTY ALARM METHODS: LED, BUZZER, TTL SIGNAL

* MEET IEC-1000-3-2 CLASS D (ACTIVE PFC)



** THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.
