RM-3U3163HE12 - RM-3U3163HE12
3U 16-Bay 12Gbps Mini-SAS E-ATX Rackmount Sever/Storage Chassis
RM-3U3163HE12 - RM-3U3163HE12
Model | RM-3U3163HE12 |
---|---|
Product Category | Rackmount Storage |
Product Sub Category | 12Gb/s (mini-SAS HD) Rackmount Storage |
Cage Color | Silver/Black |
Specifications | 19" Rackmount standard |
MotherBoard Size |
MicroATX (9.6 in. x 9.6 in.) ATX (12 in. x 9.6 in.) E-ATX (12 in. x 13 in.) Mini-ITX (6.7 in. x 6.7 in.) |
Drive Bay |
16 x External 3.5"/2.5" (w/ Hot-Swap Carriers) 2 x Internal 2.5" SSD/HDD 1 x External Slim ODD |
Switch |
Power On/Off Reset |
Power Supply |
2U Micro Redundant 3U Single |
Cooling Fan |
2 x 120mm @ Center (Optional 2 x 60mm @ Rear) |
Ports | 2 x USB2.0A @ Front |
Indicators | Power / HDD Access/ LAN1 / LAN2 / Warning |
Material | T=1.2mm SGCC |
Supported Product | |
Dimension | (WxHxD) 18x5.25x25(in) / 455x133.5x635(mm) |
Weight | 25.00lb |
Warranty | 1 Year Manufacture Limited Warranty |
Manufacture package information:
Master Box Dimension | 22-3/4" x 30-3/8" x 11-1/4" (W x L x H) |
---|---|
Master Box Weight | 33.00 lbs |
Package Quantity | 1 /Box |
RM-3U3163HE12 - RM-3U3163HE12
RM-3U3163HE12 - RM-3U3163HE12
RM-SLIDER26 | 2U-4U 26" length Slider Rail. This is a full-travel 3-sections Solid-Bearing Slider Rail. Lock open and quick release latch for easy chassis removal. |
20" Internal Mini-SAS HD Cable (SFF-8643 to SFF-8643) | Athena Power CABLE-MS8643INT20 is a 20" long internal mini-SAS HD 12Gb/s cable used for connecting a 12Gb/s host bus controller (SFF-8643) to a 12Gb/s mini-SAS HD (SFF-8643) internal backplane/... |
20" Internal Mini-SAS HD Reverse Breakout Cable (1x SFF-8643 to 4x SATA) | Athena Power CABLE-MS86434SRB20 is a 20" long internal mini-SAS HD to SATA Reverse Breakout cable used for connecting a host-controller or M/B with 4 SATA 7Pin connectors to a 12Gb/s mini-... |
