12-port 6Gb/s Mini-SAS Backplane

RM-1U1122HE6 features 12-port 6Gb/s mini-SAS backplane which supports twelve SATA-III / SAS-II 2.5” hot-swappable hard drives. Furthermore, the backplane on RM-1U1122HE6 has HDD LED indicater which provide each HDD real time status, such as: power on, HDD access and HDD overheating. Also, each of HDD on the RM-1U1122HE6 backplane is secured in an aluminum caddy with anti-vibration, EMI and triangle metal key-lock features.

Support Motherboard up to E-ATX Form Factor (12" x 13")

RM-1U1122HE6 supports the majority of mainstream motherboard ATX form factors from mini-ITX (6.7" x 6.7"), Micro ATX (9.6" x 9.6"), ATX (12" x 9.6") to E-ATX (12" x 13")

Compatible with Athena Power 1U Single and Flex ATX IPC Power Supply

Athena Power 1U single and Flex ATX form factor power supply units are compatible with RM-1U1122HE6.

Drive Bay Expandability and Convenient Front Control Panel

RM-1U1122HE6 front control panel features Power, Reset, and 1 x USB 2.0 port. Also, features system status LED indicators: System Power On, HDD Access, System Failed, LAN 1, and LAN 2, which allows users to check system's status easily.

6 x 40mm Ball Bearing Cooling Fans

6 x 40mm ball bearing cooling fans are built-in and located at specific positions for better efficient ventilation and system cooling purposes.

Full-height Expansion Slot

One full-height horizontal expansion slot for user to install an add-in card, such as a RAID controller. (1U Riser card will be required)
