AP-P4ATX35 - AP-P4ATX35

Athena Computer Power is pleased to present their new Entry level power supply for the PS2 form factor. The EXTREME series starts off at 350 Watts of true power. With its compact and light features this PSU is perfect for replacement power.
Multiple Support Function
The EXTREME 350 Watt power supply is for new OEM, PC, and server assemblies, including MiniServers and rackmount servers. This power supply is for new system assembly and compatible with many older model systems, Accounting systems, and for power supply replacement. (OEM only)
Dual Fan
With its dual fan features located at the front and back of the power supply the rear fan intakes the heat that is produced inside the server or system and pushes it through the front fan which is positioned towards the exit points of the server/system which keeps the motherboard and hard drives cool. This design allows the power supply to be able to take 100% of the heat that is generated by the interior system and pushes it out of the server/system, while some other PSU fans work differently this dual fan design is targeted to maintain a reliable source of power and keeping the system cooled. Some may second guess this dual fan feature because it will increase noise volumes but with its thermal fan speed control it will detect the amount of heat generated by the computer and spin accordingly.
Smart Auto Fan Speed Controller
With its thermal fan speed control it will detect the amount of heat generated by the computer and spin accordingly. Using this controller to detect the heat levels of the PSU it will adjust the fan speed accordingly, with this feature built in, worrying about the heat level of a PSU becomes almost non-existent.
Silence is Golden
Athena Computer Power’s designers have designed a low ripple and noise feature that is included within the PSU, taking customer’s needs into consideration for whatever they may be using this PS2 PSU for, the electrical ripple and noise has been significantly reduced for a more quiet system.
AP-P4ATX35 - AP-P4ATX35

| Model | AP-P4ATX35 | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Product Category | PS2 | ||||||||||||||
| Product Sub Category | PS2 Power Supplies | ||||||||||||||
| Output Power | 350 Watts | ||||||||||||||
| Input Votage | 115/230 Volts AC | ||||||||||||||
| Frequency | 60/50 Hz | ||||||||||||||
| MTBF | 100,000 Hours on Maximum Load at +25°C | ||||||||||||||
| Rise time | Less than 70 ms | ||||||||||||||
| Hold-up Time | 17 ms Minimum at Nominal Input Voltage | ||||||||||||||
| Output |
|
||||||||||||||
| Connectors |
ATX Connector 24 (20+4) Pin x 1 P4-12V 4 Pin x 1 SATA 15 Pin x 1 Molex 4 Pin x 4 Floppy 4 Pin x 1 |
||||||||||||||
| Dimension | 5.75" x 3.25" x 5.5" | ||||||||||||||
| Warranty | 1 Year Warranty |
Manufacture package information:
| Master Box Dimension | 16.75" x 6.375" x 18" (W x L x H) |
|---|---|
| Master Box Weight | 20.00 lbs |
| UPC Code | 821524013549 |
| Package Quantity | 10 /Box |
