AP-MPS3ATX40 - AP-MPS3ATX40
The HERCULES series has improved on power. Upgrading its overall power to 400Watts this Micro PS3 PSU can be used with many Dell, HP, IBM, Compaq, and Gateway PCs for either power supply replacement or new system assembly. Supporting up to ATX V2.2 motherboards and below and with smart silent technology, the HERCULES 400W truly has surpassed its predecessors.
The Micro PS3 Design
Micro PS3 power supplies are known mostly as a replacement power supply but it has now evolved and can be used for mini-ATX cases, custom built computers, mini-servers, and more. With the increase of wattage and efficiency the micro PS3 is a conventional PSU that can be used for multiple purposes.
Designed for custom built PCs, mini-servers, and HTPCs.
The HERCULES 400 Watt power supply will support the most current ATX motherboards V2.2 and lower. Its PCI-E 6-pin connector supports an additional VGA card. This PSU is ideal for custom-built PCs, mini-servers, and HTPCs.
Smart Auto Fan Speed Controller
Thermal fan speed control will detect the amount of heat generated by the computer. Using this controller to detect the heat levels, it will adjust the fan speed accordingly and theneed to worry about the heat levels, of a PSU, becomes almost non-existent.
AP-MPS3ATX40 - AP-MPS3ATX40
Model | AP-MPS3ATX40 | ||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Product Category | Micro PS3 | ||||||||||||||||
Product Sub Category | Hercules Series | ||||||||||||||||
Output Power | 400 Watts | ||||||||||||||||
Input Votage | 115/230 Volts AC | ||||||||||||||||
Frequency | 47/63 Hz | ||||||||||||||||
Temperature Range | Operating: 0°C ~ +50°C on Full Load; Storage & Shipping: -20°C ~ +80°C | ||||||||||||||||
MTBF | 100,000 Hours on Maximum Load at +25°C | ||||||||||||||||
Rise time | Less than 20 ms | ||||||||||||||||
Hold-up Time | 17 ms Minimum at Nominal Input Voltage | ||||||||||||||||
Output |
|
||||||||||||||||
Connectors |
ATX Connector 24 (20+4) Pin x 1 P4-12V 4 Pin x 1 PCIE 6 6 Pin x 2 SATA 15 Pin x 3 Molex 4 Pin x 3 Floppy 4 Pin x 1 Aux 6 Pin x 1 HP Video 4 Pin x 1 DELL P6 6 Pin x 1 |
||||||||||||||||
Dimension | ( L x W x H) 101.6 x 148 x 83.82 mm/ 4 x 5.86 x 3.3 in | ||||||||||||||||
Weight | 4.00lb | ||||||||||||||||
Warranty | 1 Year Manufacture Limited Warranty |
Manufacture package information:
Master Box Dimension | 18" x 20.25" x 7" (W x L x H) |
---|---|
Master Box Weight | 31.00 lbs |
UPC Code | 821524014034 |
Package Quantity | 10 /Box |
