Athena Computer Power is proud to introduce FLEX ATX power supply series. With smaller computers in demand the FLEX form factor is becoming a necessity for Mini-ITX and 1UITX computers. Not only does the FLEX hone 350 Watts of power in this compact PSU, but it also comes with additional features such as Active PFC and the Remote ON/OFF feature.
A Perfect Fit
Like its name the FLEX ATX is a compact and flexible Power Supply. Designed for 1UITX rackmounts, Mini-ITX chassis, or as a replacement PSU for IBM SurePOS, Shuttle XPC, and HP Pavillion systems. Can be used to build media servers, business server, and provide power for all types of kiosks.
Smart Auto Fan Speed Controller
Thermal fan speed control will detect the amount of heat generated by the computer. Using the speed controller to detect the heat levels, it will automatically adjust the fan speed accordingly and the need to worry about heat levels, of a PSU, becomes almost non-existent.
80PLUS Certification
Saving energy has become an important factor when choosing the appropriate power supply. The FLEX 350W is one of the latest Flex ATX PSU’s that brandishes 80PLUS Bronze certification. Providing efficiency during max and low loads, this PSU lives up to the standards of today’s world.
AP-MFATX35P8 - AP-MFATX35P8
| Model | AP-MFATX35P8 | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Product Category | Flex ATX | ||||||||||||||
| Product Sub Category | FLEX ATX | ||||||||||||||
| Output Power | 350 Watts | ||||||||||||||
| Input Votage | 88 ~ 264 Volts AC | ||||||||||||||
| Frequency | 60/50 Hz | ||||||||||||||
| Temperature Range | Operating: 0°C ~ +50°C on Full Load; Storage & Shipping: -20°C ~ +80°C | ||||||||||||||
| MTBF | 100,000 Hours on Maximum Load at +25°C | ||||||||||||||
| Rise time | Less than 20 ms | ||||||||||||||
| Hold-up Time | 17 ms Minimum at Nominal Input Voltage | ||||||||||||||
| Output |
|
||||||||||||||
| Connectors |
ATX 24 (20+4) Pin x1 EPS-12V 8 Pin x 1 P4-12V (4+4) Pin x 1 PCIE 6 Pin x 2 SATA 15 Pin x 3 Molex 4 Pin x 2 Floppy 4 Pin x 1 |
||||||||||||||
| Dimension | (L x W x H) 150 x 81.5 x 40.5 mm / 6 x 3.2 x 1.59 in | ||||||||||||||
| Weight | 2.00lb | ||||||||||||||
| Warranty | 3 Year Manufacture Limited Warranty |
