| Model | RM-2U2650X |
|---|---|
| Product Category | 2U Rackmount |
| Form Factor | 2U |
| Cage Color | Silver/Black |
| Specifications | 19" Rackmount standard |
| MotherBoard Size |
MicroATX (9.6 in. x 9.6 in.) ATX (12 in. x 9.6 in.) E-ATX (12 in. x 13 in.) Mini-ITX (6.7 in. x 6.7 in.) |
| Air Filter | Removable & Washable |
| Drive Bay |
5.25" Open Bay x4 3.5" Hidden Bay x2 2.5" Hidden Bay x2 (won't be available when ATX or EATX MB is installed) |
| External Bay | 5.25" x4 (External) |
| Internal Bay |
3.5" x2 (Internal) 2.5” x2 (Internal) |
| Switch |
Power On/Off Reset Fan Alarm |
| Power Supply |
2U Power Supply 2U Redundant Power Supply |
| Cooling Fan | 80mm Fan x 2 (Center) |
| Ports | USB 2.0 x2 (Front) |
| Indicators | LED for Power, HDD and LAN; LCD Fan Control panel |
| Expansion Slot | Full Height Expansion slot x 3 (Riser Required) |
| Material | SECC 1.2mm-2.0mm |
| Door and Lock | Single |
| Dimension | 19" x 3.5" x 25.59" (W x H x D) |
| Weight | 20.00lb |
| Warranty | 1 Year Manufacture Limited Warranty |
RM-2U2650X - RM-2U2650X
RM-2U2650X - RM-2U2650X
| Components |
|---|
| AP-U2ATX70FEP8 (Power Supply | 1U / 2U) |
